Specification for Wave Shaker Screen
| Model | Brand&Model for shaker | Mesh Range | Dimension（L*W) | Weight kgs |
| KX-12 | FLC2000 | 20-325 | 1053*697mm | 6 |
| KX-13 | FLC500 SERIES | 20-325 | 1050*695mm | 7 |
| KX-14 | FLC600 | 20-325 | 626*7107mm | 7 |
| KX-15 | HYPERFOOL | 20-325 | 1070*570mm | 7.5 |
| KX-16 | Wave | 20-325 | 1165*700mm | 6.5 |
| ATT | Other models can be customized according to your specific sizes and requirements | |||
Key Features & Advantages
- Larger Effective Screening Area
The unique three-dimensional wave structure increases the effective filtering area by 25% to 50% compared with flat screens of the same size.
This allows the same shaker to process a greater volume of drilling fluid or slurry, substantially boosting throughput.
- Higher Screening Efficiency
By increasing penetration area and optimizing material retention time on the screen surface, solid–liquid separation efficiency is greatly enhanced.
This ensures more thorough mud recovery and drier cuttings discharge.
- Ultra-Fine Solid–Liquid Separation
Using advanced structural design and precise mesh configuration, the screen can achieve separation accuracy down to 43 microns, maximizing solids removal while minimizing valuable drilling fluid loss.
- Greater Load Capacity & Durability
The multi-layer composite structure combined with a reinforced metal backing plate significantly improves impact resistance and load-bearing capacity, extending overall service life.
- Reduced Material Buildup
The corrugated surface promotes smoother material flow and minimizes the common “horseshoe effect” seen at the edges of traditional flat screens, ensuring uniform and efficient screening.
- Wide Equipment Compatibility
Designed with flexibility in mind, the screens are available in multiple sizes, structures, and mounting options, making them compatible with most mainstream shaker brands and models.
Application Fields
The corrugated shaker screen is ideal for scenarios requiring highly efficient solid–liquid separation, especially:
- Oil & Gas Drilling
A core component of shale shakers, used for the rapid and effective removal of drill cuttings from drilling mud, ensuring proper mud recycling and stable solids-control performance.
- Mining Tailings Treatment
Used for slurry dewatering, fine particle separation, and tailings management.
- Chemical & Pharmaceutical Industries
For precise material screening, grading, and filtration processes.
Summary
The Corrugated Shaker Screen represents a significant advancement in shaker screen technology.
By expanding the effective screening area and optimizing structural performance, it greatly enhances processing efficiency, screening accuracy, and service life.
It is the ideal choice for industries seeking higher capacity, improved separation performance, and superior operational reliability.
